AOHUA IP68 Kabelverbinder Wasserdicht (4 Stück) - M20 2-Polig Steckverbinder, Outdoor Erdkabel Abzweigdose für Kabel Ø5.5-10mm, 500V/20A, UL/CE/RoHS/TÜV geprüft (AH-M20-2002Z01122)

Produktbeschreibung

2 way M20 L junction box technical specifications: Certification : UL SAA CE IP67 ROHS certification Packing: 4 per pack ( Comes with 2 sets of different sized grommets to accommodate different size wires. ) Cable Range : 5.0-7.5mm / 7.5-9.5mm ( If you use a cable which is too thin, then the seal won't even cover IP67!) Waterproof rating: IP67 advanced waterproof connector Rated voltage: ≤ 300V Rated current: ≤ 20A Working Temperature: -40°C~105°C Material: plastic (nylon), seal ring (silicon) Colour: Black Connection method: The screw terminal box is easy to install, small in size and easy to install. Scope of application: Junction box connectors are suitable for quick connection of garden and outdoor displays, floor heating, beacons, cruise ships, LED billboards, LED tunnel lights, LED street lights, external wiring, etc. USEAGE: Twist the port of the waterproof connector, insert the wire directly, tighten the screw with a screwdriver to secure the wire, and then close the cap.Please make sure connect the wire correct. Note: when finished, check that all nuts are tight.
