Waveshare LTE Cat 6 Communication HAT Compatible with Raspberry Pi, LTE-A Global Multi-Band, GNSS Positioning, Comes with EM060K-GL Module

Produktbeschreibung

Integrated multi-constellation high-precision GNSS positioning: GPS, GLONASS, BDS, Galileo. Integrates rich network protocols, with multi drivers and software support, compatible with different systems including Windows / Linux / Android USB 3.1 port (USB 2.0 compatible) for connecting to PC, Raspberry Pi, or Jetson Nano to enable high-speed LTE-A network. Standard M.2 B KEY slot, compatible with QUECTEL and SIMCOM series 4G/5G M.2 modules Onboard PWR and RST control pins, enabled via DIP switch, for connecting external IO ports to control module power on/off and reset. Onboard USB-C connector, enabled via switch, for connecting standalone power supply for the module, stable and flexible, supports more loads Onboard power supply switch, reset button and LED indicator, easy to turn on/off the module and monitor the operating status Reserved 4x SMA to IPEX antenna connectors, easy to install and change the SMA antenna positions. High efficiency power supply circuit, up to 3A output current
